| Weight | 8.1 lbs (3.7 kg) |
| Dimensions | 5.7"L x 5.8"W x 12"H (14.48 cm x 14.73 cm x 30.48 cm) |
| Warranty | 2-year |
| Protection Class | IP66 dustproof and water jet resistant |
| Tripod Thread | 5/8-11 |
| Auto Shut Off | No |
| Internal Memory | 50,000 points |
| Software | Survey Pro |
| Tribrach | Detachable |
| Auto-Tracking Speed | No |
| Guide Light | Red LED |
| |
|
| Measuring Method/Reading System | Absolute encoder |
| Detection Method | No |
| Minimum Reading | 1 second/ 5 second/ 10 second |
| Accuracy | 5 second |
| Diameter of Circle | 2.4-inch (60.96 mm) |
| Display Method | No |
| |
|
| Unit of Measure (distance display) | m/ft |
| EDM Accuracy (Precision) | ±(2mm + 2ppm x D) for prism; ±(3mm + 2ppm x D) for no prism |
| Minimum Reading | Up to 1,640 ft. (500 m) |
| |
|
| Range | ±3.5' |
| Type | Dual-axis |
| Method | Liquid-electric detection |
| Setting Accuracy | No |
| |
|
| Power Source | 2 x Rechargeable Li-ion batteries |
| Battery Life | Up to 31 hours |
| Battery Life Alert | Yes |
| Voltage | 3.8-volt DC |
| |
|
| Image | Erect |
| Magnification | 3x |
| Field of View | 5° |
| Focus Range | 1.6 ft. (0.5 m) to infinity |
| |
|
| Plate/Tubular Bubble Vial | No |
| Circular Bubble Vial | 10 minutes (2 mm) |
| Electronic Level | Displayed on the LCD |
| |
|
| Length of Tube | 4.9 in (125 mm) |
| Image | Erect |
| Diameter of Objective Lens (Aperture) | 2.0 in (50 mm EDM) |
| Magnification | 30x |
| Field of View | 1°20' |
| Resolving Power | 3" |
| Minimum Focus Distance | 4.9 ft. (1.5 m) |
| Ratio of Stadia Lines | No |
| Sight Distance Precision/Focus Range | No |
| Reticle Illumination | No |
| Reflectorless | Yes |
| Quick Sights (Rough Sights) | No |
| |
|
| Type | Graphic LCD |
| Sides | Single |
| Keys | Full numeric keypad |
| Touchscreen | No |
| Backlight | Yes |
| Pixels | 128 x 64 pixels |
| |
|
| Operating | -22°F to 122°F (-30°C to 50°C) |
| Storage | -22°F to 140°F (-30°C to 60°C) |
| |
|
| Surveying and Construction | Yes |
| Mapping and GIS (geographic information systems) | Yes |
| Utilities | Yes |
| Environment Studies | Yes |
| Geomarking | Yes |
| Archaeology | Yes |
| Accident Reconstruction | Yes |
| |
|
| Single Prism | Up to 16,404 ft. (5,000 m) |
| Triple Prism | No |
| No Prism | Up to 1,640 ft. (500 m) |
| Mini Prism | No |
| Reflective Tape | No |
| Reflector Sheet | Up to 984 ft. (300 m) |
| Cat Eye/Flat Prism | No |
| 360 Degree Prism | No |
| |
|
| Coordinate Measurement Point | Yes |
| Angle and Distance Stake Out | Yes |
| Stake Out Line | Yes |
| Offsets | Yes |
| Missing Line | Yes |
| Remote Elevation | Yes |
| Resection | Yes |
| Area Calculation | Yes |
| Real-Time Video Imaging | No |
| |
|
| Fine | No |
| Rapid | No |
| Tracking | No |
| |
|
| Accuracy | No |
| Class | No |
| Wavelength | No |
| |
|
| Class | No |
| Accuracy | No |
| Laser Range | No |
| |
|
| Bluetooth | Class 2 |
| USB | USB (host) |
| Pin Port | RS-232C |
| Operating System | No |
| |
|
| Operating Range | N/A |
| Measuring Time | N/A |
| |
|
| One AP Prism | No |
| Reflective Sheet | No |
| 360 Degree Prism | No |
| Mini Prism | No |
