| Weight | 9.5 lbs (4.3 kg) |
| Dimensions | 8.1" L x 6.7" W x 12.5" H (20.57 cm x 17.02 cm x 31.75 cm) |
| Warranty | 2-year |
| Protection Class | IP66 dustproof and water jet resistant |
| Tripod Thread | 5/8-11 |
| Auto Shut Off | No |
| Internal Memory | 512 MB RAM, 4 GB flash memory |
| Software | Survey Basic, Survey Pro, and Layout Pro (sold separately) |
| Tribrach | No |
| Auto-Tracking Speed | No |
| Guide Light | No |
| |
|
| Measuring Method/Reading System | Absolute encoder |
| Detection Method | No |
| Minimum Reading | N/A |
| Accuracy | 1 second, 2 second, 3 second, 5 second |
| Diameter of Circle | 2.4-inch (60.96 mm) |
| Display Method | No |
| |
|
| Unit of Measure (distance display) | m/ft |
| EDM Accuracy (Precision) | ±(2+2 ppm x D) mm |
| Minimum Reading | No |
| |
|
| Range | ±3 degrees |
| Type | Dual-axis |
| Method | Liquid-electric detection |
| Setting Accuracy | No |
| |
|
| Power Source | 2 x Internal Li-ion battery |
| Battery Life | Up to 14 hours (continuous angle-only measurement); up to 12 hours (distance and angle measurement every 30 seconds with autofocus); up to 7 hours (continuous distance and angle measurement) |
| Battery Life Alert | No |
| Voltage | 3.6-volt |
| |
|
| Image | Erect |
| Magnification | 30x |
| Field of View | 1°25' |
| Focus Range | No |
| |
|
| Plate/Tubular Bubble Vial | No |
| Circular Bubble Vial | 10 minutes (2 mm) |
| Electronic Level | No |
| |
|
| Length of Tube | 4.9 in (124.46 mm) |
| Image | Erect |
| Diameter of Objective Lens (Aperture) | 1.77 in (45 mm) |
| Magnification | 30x |
| Field of View | 1°25' |
| Resolving Power | 3" |
| Minimum Focus Distance | 4.9 ft. (1.5 m) |
| Ratio of Stadia Lines | No |
| Sight Distance Precision/Focus Range | No |
| Reticle Illumination | No |
| Reflectorless | Yes |
| Quick Sights (Rough Sights) | No |
| |
|
| Type | Colored LCD display |
| Sides | Dual |
| Keys | No |
| Touchscreen | Yes |
| Backlight | Yes |
| Pixels | 640 x 480 pixels |
| |
|
| Operating | -4 to 122 °F (-20 to 50 °C) |
| Storage | -22 to 140 °F (-25 to 60 °C) |
| |
|
| Surveying and Construction | Yes |
| Mapping and GIS (geographic information systems) | Yes |
| Utilities | Yes |
| Environment Studies | Yes |
| Geomarking | Yes |
| Archaeology | Yes |
| Accident Reconstruction | Yes |
| |
|
| Single Prism | Up to 4.9 feet to 16,404 feet (1.5 m to 5,000 m) |
| Triple Prism | No |
| No Prism | Up to 2,625 feet (800 m) |
| Mini Prism | No |
| Reflective Tape | No |
| Reflector Sheet | Up to 4.9 feet to 984 feet (1.5 m to 300 m) |
| Cat Eye/Flat Prism | No |
| 360 Degree Prism | No |
| |
|
| Coordinate Measurement Point | Yes |
| Angle and Distance Stake Out | Yes |
| Stake Out Line | Yes |
| Offsets | Yes |
| Missing Line | Yes |
| Remote Elevation | Yes |
| Resection | Yes |
| Area Calculation | Yes |
| Real-Time Video Imaging | No |
| |
|
| Fine | N/A |
| Rapid | N/A |
| Tracking | N/A |
| |
|
| Accuracy | No |
| Class | Class 2 |
| Wavelength | No |
| |
|
| Class | 2 |
| Accuracy | N/A |
| Laser Range | N/A |
| |
|
| Bluetooth | Bluetooth Class 1 |
| USB | 2 (host and client) |
| Pin Port | RS-232C |
| Operating System | No |
| |
|
| Operating Range | N/A |
| Measuring Time | N/A |
| |
|
| One AP Prism | No |
| Reflective Sheet | No |
| 360 Degree Prism | No |
| Mini Prism | No |
