| Weight | 9.5 lbs (4.3 kg) |
| Dimensions | 8.1" L x 6.7" W x 12.5" H (20.57 cm x 17.02 cm x 31.75 cm) |
| Warranty | 2 years |
| Protection Class | IP66 dustproof and water jet resistant |
| Tripod Thread | 5/8-11 |
| Auto Shut Off | No |
| Internal Memory | 512 MB RAM, 4 GB flash memory |
| Software | Survey Basic, Survey Pro, and Layout Pro (sold separately) |
| Tribrach | No |
| Auto-Tracking Speed | No |
| Guide Light | No |
| |
|
| Measuring Method/Reading System | Absolute encoder |
| Detection Method | No |
| Minimum Reading | N/A |
| Accuracy | 1 second, 2 second, 3 second, 5 second |
| Diameter of Circle | 62 mm (2.4 in) |
| Display Method | No |
| |
|
| Unit of Measure (distance display) | m/ft |
| EDM Accuracy (Precision) | Prism: ± (1 mm + 1.5 ppm) Reflectorless: ± (2 mm + 2 ppm) |
| Minimum Reading | No |
| |
|
| Range | ±3 degrees |
| Type | Dual axis |
| Method | Liquid-electric detection |
| Setting Accuracy | No |
| |
|
| Power Source | 2x Internal Li-ion battery |
| Battery Life | Up to 19 hours (continuous angle-only measurement); up to 18 hours (distance and angle measurement every 30 seconds); up to 10.5 hours (continuous distance and angle measurement) |
| Battery Life Alert | No |
| Voltage | 3.6 volts |
| |
|
| Image | Erect |
| Magnification | 30x |
| Field of View | 1°25' |
| Focus Range | No |
| |
|
| Plate/Tubular Bubble Vial | No |
| Circular Bubble Vial | 10 minutes (2 mm) |
| Electronic Level | No |
| |
|
| Length of Tube | 4.9 in (124.46 mm) |
| Image | Erect |
| Diameter of Objective Lens (Aperture) | 1.77 in (45 mm) |
| Magnification | 30x |
| Field of View | 1°25' |
| Resolving Power | 3" |
| Minimum Focus Distance | 4.9 ft. (1.5 m) |
| Ratio of Stadia Lines | No |
| Sight Distance Precision/Focus Range | No |
| Reticle Illumination | No |
| Reflectorless | Yes |
| Quick Sights (Rough Sights) | No |
