| Weight | 11 lb |
| Dimensions | 13.1 in x 6.6 in x 6.8 in |
| Protection Class | IP55 |
| Internal Memory | 50,000 records |
| |
|
| Measuring Method/Reading System | Prism / Reflectorless |
| Detection Method | Photoelectric detection by incremental encoder |
| Minimum Reading | 1/5/10” (0.2/1/2 mgon) |
| Accuracy | Nikon N 2": 0.6 mgon / Nikon N 5": 1.5 mgon |
| Diameter of Circle | 3.46 in |
| |
|
| EDM Accuracy (Precision) | ±(2+2 ppm × D) mm |
| |
|
| Range | ±3' |
| Type | Dual axis |
| Method | Liquid-electric detection |
| |
|
| Power Source | Li-on battery |
| Battery Life | Up to 22 hours |
| |
|
| Image | Erect |
| Magnification | 3X |
| Field of View | 5° |
| Focus Range | 0.5 m (1.6 ft) to 8 |
| |
|
| Circular Bubble Vial | 10‘/2 mm |
| |
|
| Length of Tube | 4.9 in |
| Image | Erect |
| Diameter of Objective Lens (Aperture) | 1.77in |
| Magnification | 30× (18x/36x with optional eyepieces) |
| Field of View | 1°20‘ |
| Resolving Power | 3 |
| Minimum Focus Distance | 4.9 ft |
| |
|
| Type | LCD Display |
| Sides | Nikon N 2": Both / Nikon N 5": Single |
| Touchscreen | No |
| Backlight | Yes |
| Pixels | 128 × 64 pixel |
| |
|
| Operating | –4 °F to +122 °F |
| |
|
| Single Prism | 13,123 ft |
| No Prism | 1,968 ft |
| |
|
| Bluetooth | Integrated |
